Construction and Feature
■Capable of switch electric circuit with load ■Provide function of isolation | ■Contact position indication ■Used as main switch for household and similar installation |
Technical Data
Pole No.: 1P, 2P, 3P, 4P ■Rated current(A): 16, 25, 40, 63, 80, 100 ■Rated voltage: 230/400V AC ■Rated frequency: 50/60hz ■Rated short-circuit making capacity: 3kA ■Rated withstand current: 1.5kA within 1sec ■Electro-mechanical endurance: 10000 cycles ■Connection capacity: Rigid conductor 35mm2 | ■Connection terminal: □Screw terminal □Pillar terminal with clamp ■Installation: □On symmetrical din rail 35mm □Panel mounting ■Terminal Connection Height: H=15mm |
