■Protection against both overload and short circuit ■High short-circuit capacity | ■Easy mounting onto 35mm DIN rail |
■Pole No.: 1P+N ■Rated voltage: AC 230V ■Rated current (A): 6, 10, 16, 20, 25, 32，40 ■Tripping curve: B、C ■Rated short-circuit capacity (Icn): 6kA ■Rated service short-circuit capacity(Ics): 6kA ■Rated frequency: 50/60Hz ■Electro-mechanical endurance: 4000 | ■Contact position indication ■Connection terminal: Pillar terminal with clamp ■Connection capacity: Rigid conductor up to 10mm2 ■Fastening torque: 1.2Nm ■Installation: □On symmetrical DIN rail 35mm □Panel mounting ■Terminal Connection Height: H1=19mm H2=22mm |
